Description
Product Details Introduction
Vehicle Introduction and Specific Parameters：
| Foton Auman 15 Cubic Meter Mixer Truck Chassis Parameters | |||
| Vehicle Name: | Foton Auman 150,000 Liter Mixer Truck | Chinese Brand: | Foton Auman 150,000 Liter Mixer Truck |
| Engine: | Great Wall 375 Horsepower—National V | Displacement (ml): | 11596 |
| Dimensions: | 10510x2495x3969 | Mixing Volume: | 15 Cubic Meters (150,000 Liter Mixer Truck) |
| Total Weight: | 25000 (kg) | Number of Spring Leaves: | 13/14/12, Left 14 Right 13 / Left 14 Right 13 / 12 |
| Curb Weight: | 14500 (kg) | Rated Load: | 10370 (kg) |
| Axle Load: | 6500/6500/18000 | Wheelbase: | 4300+1350 |
| Number of Axles: | 3 (Three Axles) (6×4) | Maximum Speed: | 83 (km/h) |
| Transmission: | Shaanxi 9-Speed (Torque 1800) | Front and Rear Axles: | 90 Front Axle, Mercedes-Benz 16 Ton Dual Rear Axles |
| Number of Tires: | 10+1 | Tire Specifications: | 12.00R20 Original Factory Steel Wire Tires |
| Front Track: | 2022, 2041 | Rear Track: | 1830/1830 |
| Chassis Emission Standard: | GB17691-2005 National V, GB3847-2005 (National V Standard – Hassle-Free Registration) | ||
Mixer Truck Tank Parameters：
| Tank Material: | Alloy Steel (Special Wear-Resistant Material—Increases Tank Life by 3 Times or More) | Cylinder Material: | 16Mn Steel 6mm Alloy Steel |
| Blade Material: | Baosteel 520 5mm Alloy Steel (Wear-Resistant Strips Added to Increase Service Life) | Head Material: | 8mm Alloy Steel |
| Reducer: | German ZF Reducer / Italian Bonfiglioli PMP (Pure Import) | Hydraulic System: | German Rexroth, /American Eaton / American Sauer-Danfoss / Italian PMP (Pure Import) |
| Water Supply System: | 400L Water Tank Pressure Water Supply | Cooling System: | Kaidi Radiator / Xinduo Radiator |
| Feeding Speed: | Feeding Speed m³/min ≥ 3 | Discharge Speed: | Discharge Speed m³/min ≥ 2 |
| Discharge Residual Rate: | Discharge Residual Rate (%) ≤ 0.5 | Operation Method: | Three-Sided Operation from Both Sides and Cab |
| Discharge Range: | 180° Up, Down, Left, and Right Height Adjustment | Safety Device: | Leakage Receiving Device Installed |
Advantages of the Mixing Tank Body：
| Reducer: | Internationally imported brands, such as German Rexroth, ItalianPMP,and Italian Bonfiglioli, with strong load-bearing capacity and low failure rate. |
|
Hydraulic System: |
All equipped with internationally renowned hydraulic systems, including German Rexroth, American Eaton, Ameican Sauer, and Italian PMP, ensuring more stable tank operation, faster discharge speed, and lower residual rate! |
|
Supporting Facilities: |
The vehicle is designed for convenient and fast loading and unloading, with multi-functional operation methods, saving time,effort, and worry! |
|
After-Sales Service: |
The tank reducer comes with a one-year or 30,000-kilometer warranty. |
Product Details Display
